McCloskey I4C Crusher

April 28, 2021

McCloskey I4C impact crusher is a compact unit with an impactor measuring 41.3 inches in diameter and 44.3 inches wide. Powered by a 375-horsepower engine, the crusher’s transport measurements are 10 feet 6 inches high, 51 feet 10 inches long, and 9 feet 10 inches wide.

The McCloskey I4C compact impact crusher has been designed with a deep chamber for tramp release space. With an aggressive blow bar and apron design, 4 bar variable speed rotor, and three crush zones with an optional fourth strike, the I4C can be set up as a primary or secondary crusher.

A new asymmetric feeder reduces bridging that can occur in some applications and, combined with the single unit feeder-hopper construction, delivers motion and vibration for the material as it moves into the impact chamber. The I4C has a curved belt on the main conveyor to manage material delivered to a 4-meter-high stockpile. The belt has quick release and ground level access for maintenance and service.

The I4C crusher has a chamber door safety sensor, built in safety shutdown functions, and a chamber safety arm.
